Choosing wheels and tyres for the Ford Ranger Super Duty comes down to the appearance you want, the load you carry and where you travel.
There isn’t one combination every owner should run. You might prefer the factory tyre size, a slightly larger touring setup or the more aggressive appearance of 35s. The important details are suitable load ratings, correct fitment, road legality and replacement availability when travelling remotely.
This guide brings together my own fitment observations, practical recommendations and current aftermarket wheel options.
The Factory Starting Point
The Ranger Super Duty uses an eight-stud wheel configuration, so wheels designed for the standard six-stud Next-Gen Ranger are not interchangeable.
Ford lists 18-inch wheels and LT275/70R18 tyres. Standard models receive steel wheels, while the XLT receives Super Duty-branded alloys. Ford specifications.
The factory +55 offset is the reference point used for the comparisons below.
Wheel Load Ratings: Start at 1,500 kg
My recommendation is a minimum load rating of 1,500 kg per wheel.
The Super Duty is designed to carry substantial weight. Selecting wheels purely because they have the right stud pattern or look good overlooks one of the most important specifications.
Check the rating for the exact size, offset and part number you are buying. Different versions of the same wheel design can have different capacities.
This is my recommended starting point, rather than a universal legal minimum. The wheel supplier should confirm suitability for your vehicle and any approved modifications.
Current Ranger Super Duty Wheel Options
These manufacturers and distributors list the following eight-stud options:
| Wheel | Size | Stud pattern | Offset | Load rating per wheel |
|---|---|---|---|---|
| CSA Thunder HD | 18×9 | 8×170 | +35 | 1,650 kg |
| Mayhem Convoy | 18×9 | 8×170 | +35 | 1,600 kg |
| Method 703-HD | 18×9 | 8×170 | +40 | 1,651 kg |
CSA confirms the Thunder HD specifications in its fitment table. Dynamic Wheel Co lists the Convoy specifically for the Super Duty, and Method Australia lists the eight-stud +40 version of its 703-HD. Sources: CSA Thunder, Mayhem Convoy and Method 703-HD.
All three exceed my recommended minimum. Choose the design you prefer, then confirm the exact fitment and stock availability with the supplier.
Choosing Your Tyre Size
The sizes worth comparing include:
| Tyre size | Why you might choose it |
|---|---|
| LT275/70R18 | Retain the factory size |
| LT285/70R18 | A modest increase over standard |
| LT295/70R18 | A larger tyre within my practical recommendation for remote replacement availability |
| LT35×10.5R18 | A narrower option for owners wanting 35s |
| LT35×12.5R18 | A wider 35-inch option with a more aggressive appearance |
The tyre size is your choice. I wouldn’t automatically assign one size to every work vehicle and another to every touring vehicle.
Personally, I prefer the appearance of 35s on the Super Duty. They suit its proportions and give it the stance I like. That is a styling preference; it doesn’t mean every owner needs them.
Use LT Tyres With Suitable Ratings
My recommendation is to stay with Light Truck — LT — tyres.
However, the LT marking alone does not establish that a tyre can carry the required load. Check its load index, speed rating and approved rim-width range against your vehicle’s requirements. Replacement tyres must satisfy the applicable load and speed-rating rules. NSW alternative wheels and tyres guidelines.
Tyre Availability in the Outback
If you regularly travel through the outback, replacement availability deserves serious consideration.
295/70R18 is the largest size I would recommend when finding a replacement without a lengthy wait is a priority.
You can choose larger tyres, including 35s, but I would plan around having fewer replacement options and potentially needing to freight a tyre into a remote location.
A tyre that is readily available near home may be difficult to source along your route. Before leaving, check with suppliers in the areas you will visit and confirm they can supply a replacement with the required load rating.
For an outback-focused build, I would make this decision before choosing the wheel design.
Do 35-Inch Tyres Fit a Standard Ranger Super Duty?
In my fitment checks, 35×12.5R18 tyres fitted on the factory +55 wheels without a suspension lift, trimming or other vehicle modifications.
Clearance to the upper control arm was tight — only a few millimetres — but the combination I checked cleared.
That corrects an important point: a more aggressive offset is not automatically required just to physically fit 35s.
Moving to a lower positive offset shifts the wheel outward and can improve inner clearance. This gives owners another option if they want a wider stance.
These are my observations from the tyres checked. Actual dimensions vary between tyre models, so confirm clearance for your chosen combination through steering and suspension movement. Physical clearance also needs to be considered separately from the tyre manufacturer’s approved rim-width range. NSW fitment guidelines.
What About 37s?
37s are a different proposition.
They do not provide adequate clearance on the standard setup I checked and prevent normal steering movement. Modifications are required.
They also exceed the usual 50 mm tyre-diameter increase allowance applicable to relevant off-road and goods-vehicle categories. They are not a straightforward road-legal upgrade; any approval pathway depends on your jurisdiction and vehicle classification. National Code of Practice, Section LS.
Wheel Width and Offset: Choosing Your Stance
Wheel width and offset have a strong influence on appearance. You can choose a restrained factory-style stance or something more aggressive.
However, offset also changes inner clearance and wheel track. Wheel width must suit the tyre you intend to fit.
Using the factory +55 offset as the baseline, the following changes apply with the same axles:
| Offset | Wheel centre moves outward per side | Total track increase |
|---|---|---|
| +55 | 0 mm | 0 mm |
| +40 | 15 mm | 30 mm |
| +35 | 20 mm | 40 mm |
| +18 | 37 mm | 74 mm |
These figures describe the wheel centre position. A wider wheel also changes where its inner and outer edges sit.
A +35 or +40 wheel gives a wider stance than factory while keeping the calculated track increase below 50 mm. That alone does not establish that the complete wheel-and-tyre combination is legal.
Is +18 Offset Legal?
A +18 offset increases track by approximately 74 mm compared with +55. That exceeds the common 50 mm allowance and is generally outside standard road-legal limits in most states.
For example, NSW limits track increases for relevant off-road and goods-vehicle categories to 50 mm beyond the manufacturer’s specified maximum. State rules and approval pathways must still be checked for your vehicle. Sources: NSW guidelines and National Code of Practice.
Owners may choose the appearance of +18 wheels, and it is useful to show what that combination looks like. It should be clearly identified as exceeding standard track limits. Adding flares does not reduce the track increase.
Watch the Different Wheel and Tyre Combinations
I made a video showing different Ranger Super Duty wheel and tyre combinations so you can compare their appearance.
Watch: Ranger Super Duty — Wheel & Tyre Combos
Use it alongside the specifications above when deciding how you want your own vehicle to sit.
Everyday Driving, Towing and Touring
Appearance is only part of the decision.
Larger or heavier tyres can affect fuel consumption, acceleration, braking and speedometer accuracy. Tread choice also influences road noise and how the vehicle feels during everyday driving.
When towing or carrying substantial weight, pay particular attention to tyre load capacity and pressures appropriate to the actual axle loads.
For remote touring, consider the spare you carry and whether a suitable replacement can be sourced along your route.
What I Would Choose
For appearance, my preference is 35×12.5R18. I like the way 35s fill out the Super Duty, and my fitment checks showed that a lift is not automatically necessary.
If remote replacement availability is the priority, 295/70R18 is my practical upper recommendation. A smaller size may suit your route and supplier options better.
For aftermarket wheels, I would start with a minimum 1,500 kg rating per wheel, then choose a suitable width, offset and design.
You can build the Super Duty around your own preferences. The aim is to understand the fitment, load capacity and legal position before buying.
For other practical upgrades, read our guide to Ranger Super Duty accessories: what to upgrade first.
